16-Port 10/100Mbps Desktop Switch
kecepatan Ethernet yang cepat Auto MDI/MDIX Plug and Play Environmentally Protection

Out of stock

SKU: SW16D Category:

Hardware Features
Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, CSMA / CD
Interfaces 16*10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Power Supply 9V DC/800mA
Dimensions(L x W x H) 8.9 x 5.0 x 1.8in. (227 x 127 x 45mm)
LED Indicators 1*Power, Link/Act (1~24)
MAC Address Learning Auto-learning, auto update
Multicast IGMP Snooping
MAC Address Table 4K
Switching Capacity 3.2Gbps
Network Media 10BASE-T: UTP Cat 3, 4, 5 cable
100BASE-TX: UTP Cat 5, 5e or above cable
Frame Filtering 10Mbps: 14,880pps
100Mbps: 148,800pps
Transfer Method Store-and-Forward
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
Package Contents SW16D Desktop Switch
Power Adapter
Quick Installation Guide
