W1026P menyediakan port 24 10/100Mbps dan 2 Gigabit SFP Slots, yang khusus dikembangkan untuk usaha kecil dan menengah.Port 1-24 mematuhi standar pasokan daya IEEE802.3af dan dapat menyediakan daya saat bertukar data dengan AP, kamera IP, dan telepon IP melalui kabel CAT5.Cakupan power supply maksimum hingga 100 meter.Fitur lanjutan seperti ACL, 802.1X Authentication, Port Security, IP Filtering, Storm control, IGMP Snooping dan IP Source Guard memberi Anda strategi keamanan yang kuat.
SKU: SW1026P Category:

Share this product

Power over Ethernet
PoE IEEE 802.3af-compliant Power over Ethernet
Parameter PoE Maximum PoE power output of each port is 15.4 W
Power Mode PoE through pin:1 2 4 5 +,3 6 7 8 –
Power Distance Up to 100 meters
Interface Performance
PoE Interface Port:RJ45
Port data rate:24×100Mbps+2×1000Mbps
Cable Type:Standard CAT5 UTP or higher
Transmission Distance:100 Meters
Optical Interface Optical Interface:SFP
Data rate:1.25Gbps
FiberType:Multi-Mode62.5/125µm and Single-Mode8.3/125µm
Transmission Distance:Multi-Mode 550m and Single-Mode10/40/80Km
Standard&Protocol IEEE 802.3 i 10 BASE-T;
IEEE 802.3 U 100 BASE-T;
Packet forwarding rate:1.2Mpps(9 ports)
IEEE 802.3 ab/z 1000 BASE-TX;
IEEE 802.3 x Flow Control;
IEEE 802.3 af/at Power over Ethernet
Performance Store and Forward
Transmission Mode:Full duplex/Half duplex
Addressing:48-bit MAC address
MAC address entries:3K MAC
Network delay:For data transmission from 100Mbps to 100Mbps,the latency of 64 data frames is not more than 20 microseconds
MTBF:100,000 hours
Manage by WEB browser interface
LED Indicator Link/Act, PoE Status,System, Power
Interface Protection Meet the requirement of IEC61000-4-2(ESD)±15KV(air),±8KV(contanc)and withstand 8/20us 24A(12A)
Management IEEE802.1Q Static VLAN(128)
IEEE 802.1p CoS
Port-based QoS
DSCP-based QoS
802.3ad Link Aggregation(Manual or LACP)
802.1D Spanning Tree Protocol
SNMP v1/v2/v3
RFC 1643 Ethernet Interface MIB
RFC 1493 Bridge MIB
RMON Group 1,2,3,9
RFC 2131 DHCP Client
IEEE 802.1x Port-based security access control
Port and Mac address binding
It can manage traffic and rate limiting based on broadcast,multicast, source MAC/IP address, destination MAC/IP address.
IGMP Snooping v1/v2
Port-based ingress/egress traffic rate limiting
Port Mirroring
Configuration management based on Web browser
Upload/Download of configuration file
Support Radius
Support TACACS+
